KOZ Series is a powerful heating solution with highly efficient, automated systems for industrial and commercial areas.

While offering easy operation with its advanced automation features, it offers a long-lasting and economical heating system with its durable structure.

Experience a more efficient, more economical and more comfortable heating experience with Kozlusan KOZ Series!

Color Option

Red

Our product provides economy
with its highly efficient body design and
turbulators in smoke pipes. It offers comfort to the user with its rich
functions such as automatic loading, ash removal,
automatic mixing system etc.

Whatsapp Support

General Features

Technical Specifications

Documents

Images & Videos

It offers ‘Automatic Fuel Loading’ by rotating the auger with the help of the electronic fuel supply motor. In this way, you can warm up without getting up from your place and with balanced fuel consumption.

Automatic Fuel Loading

Where does the waste from all these cleaned areas go? The answer to this is given by the "Automatic Ash Removal" system... We transfer the cleaned ash and pellet residues to the ash box located outside the device. In this way, you can empty the ash box in a more sterilized and hygienic way at regular intervals.

Automatic Ignition

Of course, you do not need to ignite the loaded fuel with your hand. The device will automatically load the fuel level in line with the temperature value you set, and then automatically ignite the ignition within a short period of 5 minutes to make it work.

Automatic Ash Extraction

The slag layer that forms on the top of the coal causes the flame to weaken and unburned coal to be wasted. However, our Automatic Stirring Furnace eliminates this problem, ensuring 100% efficient combustion . Thanks to its innovative design, it always delivers a strong and effective heat , minimizing energy losses. Be one step ahead now for high efficiency, maximum performance!

Automatic Mixing

With the boiler sensor and boiler pump start-up feature, your boiler is now guaranteed to produce hot water in summer and winter! This smart system, which meets your hot water needs in every season throughout the year, makes your life easier with its energy efficiency and superior performance. Always enjoy hot water , do not compromise on your comfort!

Boiler Integration

Thanks to Sleep Mode, your boiler is automatically ignited and activated at specific time periods to keep the fire alive during long standby periods. This innovative feature offers uninterrupted comfort and maximum energy savings. Your heat is always at the ideal level, your energy efficiency is at the highest level!

Sleep Mode

It offers ‘Automatic Fuel Loading’ by rotating the auger with the help of the electronic fuel supply motor. In this way, you can warm up without getting up from your place and with balanced fuel consumption.

Automatic Fuel Loading

Where does the waste from all these cleaned areas go? The answer to this is given by the "Automatic Ash Removal" system... We transfer the cleaned ash and pellet residues to the ash box located outside the device. In this way, you can empty the ash box in a more sterilized and hygienic way at regular intervals.

Automatic Ignition

Of course, you do not need to ignite the loaded fuel with your hand. The device will automatically load the fuel level in line with the temperature value you set, and then automatically ignite the ignition within a short period of 5 minutes to make it work.

Automatic Ash Extraction

The slag layer that forms on the top of the coal causes the flame to weaken and unburned coal to be wasted. However, our Automatic Stirring Furnace eliminates this problem, ensuring 100% efficient combustion . Thanks to its innovative design, it always delivers a strong and effective heat , minimizing energy losses. Be one step ahead now for high efficiency, maximum performance!

Automatic Mixing

With the boiler sensor and boiler pump start-up feature, your boiler is now guaranteed to produce hot water in summer and winter! This smart system, which meets your hot water needs in every season throughout the year, makes your life easier with its energy efficiency and superior performance. Always enjoy hot water , do not compromise on your comfort!

Boiler Integration

Thanks to Sleep Mode, your boiler is automatically ignited and activated at specific time periods to keep the fire alive during long standby periods. This innovative feature offers uninterrupted comfort and maximum energy savings. Your heat is always at the ideal level, your energy efficiency is at the highest level!

Sleep Mode

It offers ‘Automatic Fuel Loading’ by rotating the auger with the help of the electronic fuel supply motor. In this way, you can warm up without getting up from your place and with balanced fuel consumption.

Automatic Fuel Loading

Where does the waste from all these cleaned areas go? The answer to this is given by the "Automatic Ash Removal" system... We transfer the cleaned ash and pellet residues to the ash box located outside the device. In this way, you can empty the ash box in a more sterilized and hygienic way at regular intervals.

Automatic Ignition

Of course, you do not need to ignite the loaded fuel with your hand. The device will automatically load the fuel level in line with the temperature value you set, and then automatically ignite the ignition within a short period of 5 minutes to make it work.

Automatic Ash Extraction

The slag layer that forms on the top of the coal causes the flame to weaken and unburned coal to be wasted. However, our Automatic Stirring Furnace eliminates this problem, ensuring 100% efficient combustion . Thanks to its innovative design, it always delivers a strong and effective heat , minimizing energy losses. Be one step ahead now for high efficiency, maximum performance!

Automatic Mixing

With the boiler sensor and boiler pump start-up feature, your boiler is now guaranteed to produce hot water in summer and winter! This smart system, which meets your hot water needs in every season throughout the year, makes your life easier with its energy efficiency and superior performance. Always enjoy hot water , do not compromise on your comfort!

Boiler Integration

Thanks to Sleep Mode, your boiler is automatically ignited and activated at specific time periods to keep the fire alive during long standby periods. This innovative feature offers uninterrupted comfort and maximum energy savings. Your heat is always at the ideal level, your energy efficiency is at the highest level!

Sleep Mode

MODEL

Capacity kW	150
Width (A) mm	1850
Length (B) mm	2000
Height (C) mm	1600
Cold Water Inlet Height (D) mm	530
Hot Water Outlet Height (E) mm	1600
Flue Outlet Height (F) mm	1260
Flue Diameter mm	250
Flow – Return inch	2 1/2
Expansion Outlet inch	1 1/2
Fill – Drain inch	1/2
Weight kg	960
Water Capacity lt	350
Tank Capacity lt	230
Max. Operating Pressure bar	3
Test Pressure bar	4.3
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	180
Fan Power W	240
Ash Box Capacity l	50
Operating Voltage and Frequency V/Hz	230/50
Operating Current A	16

Capacity kW	175
Width (A) mm	2050
Length (B) mm	2100
Height (C) mm	1900
Cold Water Inlet Height (D) mm	500
Hot Water Outlet Height (E) mm	1900
Flue Outlet Height (F) mm	1300
Flue Diameter mm	300
Flow – Return inch	2 1/2
Expansion Outlet inch	1 1/2
Fill – Drain inch	1
Weight kg	1540
Water Capacity lt	470
Tank Capacity lt	450
Max. Operating Pressure bar	3
Test Pressure bar	4.3
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	750
Fan Power W	550
Ash Box Capacity l	95
Operating Voltage and Frequency V/Hz	230/50
Operating Current A	16

Capacity kW	209
Width (A) mm	2050
Length (B) mm	2100
Height (C) mm	2000
Cold Water Inlet Height (D) mm	500
Hot Water Outlet Height (E) mm	2000
Flue Outlet Height (F) mm	1400
Flue Diameter mm	300
Flow – Return inch	2 1/2
Expansion Outlet inch	1 1/2
Fill – Drain inch	1
Weight kg	1600
Water Capacity lt	520
Tank Capacity lt	450
Max. Operating Pressure bar	3
Test Pressure bar	4.3
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	750
Fan Power W	550
Ash Box Capacity l	95
Operating Voltage and Frequency V/Hz	230/50
Operating Current A	16

Capacity kW	232
Width (A) mm	2050
Length (B) mm	2200
Height (C) mm	2000
Cold Water Inlet Height (D) mm	500
Hot Water Outlet Height (E) mm	2000
Flue Outlet Height (F) mm	1400
Flue Diameter mm	300
Flow – Return inch	2 1/2
Expansion Outlet inch	1 1/2
Fill – Drain inch	1
Weight kg	1715
Water Capacity lt	585
Tank Capacity lt	450
Max. Operating Pressure bar	3
Test Pressure bar	4.3
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	750
Fan Power W	550
Ash Box Capacity l	95
Operating Voltage and Frequency V/Hz	230/50
Operating Current A	16

Capacity kW	290
Width (A) mm	2400
Length (B) mm	2300
Height (C) mm	2200
Cold Water Inlet Height (D) mm	650
Hot Water Outlet Height (E) mm	2200
Flue Outlet Height (F) mm	1600
Flue Diameter mm	300
Flow – Return inch	2 1/2
Expansion Outlet inch	1 1/2
Fill – Drain inch	1
Weight kg	2080
Water Capacity lt	1050
Tank Capacity lt	600
Max. Operating Pressure bar	3
Test Pressure bar	4.3
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	750
Fan Power W	550
Ash Box Capacity l	95
Operating Voltage and Frequency V/Hz	230/50
Operating Current A	16

Capacity kW	348
Width (A) mm	2400
Length (B) mm	2850
Height (C) mm	2250
Cold Water Inlet Height (D) mm	720
Hot Water Outlet Height (E) mm	2250
Flue Outlet Height (F) mm	1750
Flue Diameter mm	400
Flow – Return inch	3
Expansion Outlet inch	2
Fill – Drain inch	2
Weight kg	3490
Water Capacity lt	1350
Tank Capacity lt	600
Max. Operating Pressure bar	5
Test Pressure bar	7.15
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	750
Fan Power W	550
Ash Box Capacity l	95
Operating Voltage and Frequency V/Hz	380/50
Operating Current A	18

Capacity kW	465
Width (A) mm	2500
Length (B) mm	3250
Height (C) mm	2250
Cold Water Inlet Height (D) mm	720
Hot Water Outlet Height (E) mm	2250
Flue Outlet Height (F) mm	1900
Flue Diameter mm	400
Flow – Return inch	3
Expansion Outlet inch	2
Fill – Drain inch	2
Weight kg	3500
Water Capacity lt	1700
Tank Capacity lt	600
Max. Operating Pressure bar	5
Test Pressure bar	7.15
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	750
Fan Power W	550
Ash Box Capacity l	95
Operating Voltage and Frequency V/Hz	380/50
Operating Current A	18

Capacity kW	581
Width (A) mm	2800
Length (B) mm	3550
Height (C) mm	2550
Cold Water Inlet Height (D) mm	730
Hot Water Outlet Height (E) mm	2250
Flue Outlet Height (F) mm	1950
Flue Diameter mm	500
Flow – Return inch	4
Expansion Outlet inch	2
Fill – Drain inch	2
Weight kg	4000
Water Capacity lt	2500
Tank Capacity lt	600
Max. Operating Pressure bar	5
Test Pressure bar	7.15
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	750
Fan Power W	550
Ash Box Capacity l	95
Operating Voltage and Frequency V/Hz	380/50
Operating Current A	18

Capacity kW	697
Width (A) mm	2750
Length (B) mm	3550
Height (C) mm	2550
Cold Water Inlet Height (D) mm	730
Hot Water Outlet Height (E) mm	2250
Flue Outlet Height (F) mm	1950
Flue Diameter mm	500
Flow – Return inch	4
Expansion Outlet inch	2
Fill – Drain inch	2
Weight kg	5550
Water Capacity lt	3380
Tank Capacity lt	600
Max. Operating Pressure bar	5
Test Pressure bar	7.15
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	750
Fan Power W	2×550
Ash Box Capacity l	95
Operating Voltage and Frequency V/Hz	380/50
Operating Current A	18

Capacity kW	814
Width (A) mm	3400
Length (B) mm	4050
Height (C) mm	2800
Cold Water Inlet Height (D) mm	790
Hot Water Outlet Height (E) mm	2800
Flue Outlet Height (F) mm	2250
Flue Diameter mm	600
Flow – Return inch	5
Expansion Outlet inch	2 1/2
Fill – Drain inch	2 1/2
Weight kg	6000
Water Capacity lt	4260
Tank Capacity lt	1600
Max. Operating Pressure bar	5
Test Pressure bar	7.15
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	750
Fan Power W	2×550
Ash Box Capacity l	95
Operating Voltage and Frequency V/Hz	380/50
Operating Current A	18

Capacity kW	930
Width (A) mm	3400
Length (B) mm	4250
Height (C) mm	2800
Cold Water Inlet Height (D) mm	790
Hot Water Outlet Height (E) mm	2800
Flue Outlet Height (F) mm	2250
Flue Diameter mm	600
Flow – Return inch	5
Expansion Outlet inch	2 1/2
Fill – Drain inch	2 1/2
Weight kg	6770
Water Capacity lt	4670
Tank Capacity lt	1600
Max. Operating Pressure bar	5
Test Pressure bar	7.15
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	1100
Fan Power W	2×550
Ash Box Capacity l	95
Operating Voltage and Frequency V/Hz	380/50
Operating Current A	24

Capacity kW	1160
Width (A) mm	3400
Length (B) mm	4500
Height (C) mm	3000
Cold Water Inlet Height (D) mm	800
Hot Water Outlet Height (E) mm	3000
Flue Outlet Height (F) mm	2350
Flue Diameter mm	600
Flow – Return inch	5
Expansion Outlet inch	2 1/2
Fill – Drain inch	2 1/2
Weight kg	7500
Water Capacity lt	4800
Tank Capacity lt	1600
Max. Operating Pressure bar	5
Test Pressure bar	7.15
Temperature Control Range °C	45-85
Max. Operating Temperature °C	90
Reducer Power W	750
Fan Power W	2×550
Ash Box Capacity l	95
Operating Voltage and Frequency V/Hz	380/50
Operating Current A	24
